Description

REF-

REF+

COS+

COS-

SIN+

null

null

null

SIN-

EXC-PG03

Rotate transformer

COS+、COS-

Cosine signal

SIN+、SIN-

Sine signal

REF+、REF-

Reference voltage signal

Null

Null

F00.08 = 3

VC control mode

F08.24 = 2

Select as rotary transformer

F08.00

Motor 1 type selection

0：Three phase asynchronous motors

0

×

1：AC permanent magnet synchronous motor

2：Single phase asynchronous motors（Remove capacity）

3：Single phase asynchronous motors（No need to remove capacity）

F08.01

Power rating of motor 1

0.1～1000.0kW

Model

defined

×

F08.02

 Rated voltage of motor 1

60～660V

Model

defined

×

F08.03

Rated current of motor 1

0.1～1500.0A

Model

defined

×

F08.04

Rated frequency of

motor 1

20.00～Fmax

Model

defined

×

F08.05

Rated speed of motor 1

1～30000

Model

defined

×

F08.08

Stator resistance R1 of

async motor 1

0.001～65.535Ω

Model

defined

×

F08.09

Rotor resistance R2 of

async motor 1

0.001～65.535Ω

Model

defined

×

F08.10

Leakage inductance L1

of async motor 1

0.001～65.535mH

Model

defined

×

F08.11

Mutual inductance L2 of

asynchronous motor 1

0.1～6553.5mH

Model

defined

×

F08.12

No-load current of

async motor 1

0.1～1500.0A

Model

defined

×

F08.13

Field weakening coeff 1

of async motor 1

0.0～100.0

87%

×

F08.14

Field weakening coeff 2

of async motor 1

0.0～100.0

75%

×

F08.15

Field weakening coeff 3

of async motor 1

0.0～100.0

70%

×

F08.16

Stator resistance of

synchronous motor

0.001～65.535Ω

Model

defined

×

F08.17

Synchronous motor direct shaft inductance

0.01～655.35mH

Model

defined
